What Is CBOR? Binary JSON for Passkeys, COSE and IoT — Explained

When you create a passkey, your browser and the site exchange a blob of binary data — and that blob is CBOR. CBOR is a compact, JSON-like binary format that shows up in WebAuthn, COSE-signed tokens and a lot of IoT, yet most developers never see inside it. This guide explains how CBOR works, how a single byte tells the decoder what comes next, why it beats JSON when size matters, and how to read one for yourself with the CBOR Decoder.

CBOR in one sentence

CBOR (Concise Binary Object Representation, RFC 8949) is binary JSON with extra types. It encodes the same data model as JSON — numbers, strings, arrays, maps, booleans, null — but in a smaller binary form, and it adds native byte strings, tags, and exact 64-bit integers. The trade-off versus JSON is readability for efficiency: you give up being able to read it in a text editor in exchange for a payload that is smaller on the wire and quicker for a constrained device to parse.

Two design goals shape everything about the format. First, messages should be small without a compression step, so even a tiny microcontroller can produce and consume them. Second, a decoder should be able to walk any message without a schema — the bytes themselves carry enough information to reconstruct the structure. Those two goals are why CBOR looks the way it does.

How a CBOR item is encoded

The elegant part: every data item starts with a single “initial byte” that splits into two pieces:

initial byte = (major type × 32) + additional info

The major type (top 3 bits) says what kind of thing it is; the additional info (low 5 bits) gives a small value directly, or says how many following bytes hold the value or length.

Major type	Meaning	Example diagnostic
0	Unsigned integer	1000
1	Negative integer	-500
2	Byte string	h'01020304'
3	Text string (UTF-8)	"name"
4	Array	[1, 2, 3]
5	Map (key/value pairs)	{"a": 1}
6	Tag (semantic label on the next item)	0("2013-03-21T20:04:00Z")
7	Floats and simple values (true/false/null)	1.5, true, null

The additional-info field has a neat convention. Values 0–23 encode a small number directly in the initial byte, so the tiniest integers cost a single byte. Value 24 means “one more byte follows”, 25 means “two bytes follow”, 26 means “four bytes”, and 27 means “eight bytes” — big-endian in every case. That is how CBOR represents anything from a one-digit count to a full 64-bit integer with no ambiguity and no wasted space.

A worked example, byte by byte

Take the byte 0x01. In binary that is 000 00001: major type 0 (unsigned integer), additional info 1 — so it is simply the integer 1, encoded in one byte.

Now take 0x19 0x03 0xe8. The initial byte 0x19 is 000 11001: major type 0, additional info 25, which means “two bytes follow”. Those two bytes, 0x03e8, are 1000 in hex — so the whole three-byte sequence decodes to the integer 1000. Strings and arrays follow the identical pattern: the initial byte encodes the type and a length, then the contents come immediately after. A text string of five characters, for instance, starts with major type 3 and additional info 5, then the five UTF-8 bytes.

Because the type and length always come first, a decoder never has to guess or look ahead — it reads one item, knows exactly how long it is, and moves to the next. That is what “self-describing” means in practice.

Diagnostic notation: CBOR you can read

Because raw CBOR is binary, the RFC defines diagnostic notation — a text form that looks like JSON but is precise about CBOR’s extra types:

{"age": 1000, "name": "Chloe"}     ← a map
[1, 2, 3]                          ← an array
h'01020304'                        ← a byte string
0("2013-03-21T20:04:00Z")          ← tag 0 (a date-time string)
1.5   Infinity   NaN               ← floats (always with a point)

Byte strings become h'…', tags become N(value), and floats always carry a decimal point so you can tell 1.0 (a float) from 1 (an integer) — a distinction JSON simply cannot express. A decoder prints this so a binary message becomes legible at a glance, which is exactly what you want when you are staring at a hex dump and trying to work out what a device sent.

CBOR vs JSON vs MessagePack

CBOR is not the only compact format, and it is worth knowing where it sits. The table below compares it with plain JSON and with MessagePack, the other well-known binary-JSON encoding.

Feature	JSON	CBOR	MessagePack
Form	Text	Binary	Binary
Human-readable directly	Yes	No (use diagnostic notation)	No
Native binary (byte strings)	No — base64 in a string	Yes	Yes
Semantic tags (dates, big nums, etc.)	No	Yes	No (built-in extension type)
Formal standard	RFC 8259	RFC 8949	Community spec
Self-describing (no schema)	Yes	Yes	Yes
Used by WebAuthn / COSE	No	Yes	No

The practical takeaway: JSON stays king for anything a human reads or edits and for universal tooling; CBOR wins when you need a standardised, tag-rich binary format — which is precisely why the security world chose it. CBOR and MessagePack overlap heavily, but they use different byte encodings, so a MessagePack blob will not decode as CBOR or the other way round.

Why you’ll meet CBOR: passkeys and COSE

The reason CBOR matters to web developers today is WebAuthn / passkeys. When a passkey is created, the authenticator returns an attestation object — a CBOR map containing the format (fmt), the authenticator data (authData, itself a byte string) and an attestation statement. The public keys inside use COSE (CBOR Object Signing and Encryption), which is also CBOR: a COSE key is a small CBOR map whose integer keys identify the key type, algorithm and curve parameters.

If you are debugging a registration flow and the browser hands you an attestationObject, decoding that CBOR is the only way to see what the authenticator actually sent — which algorithm it chose, what the credential public key looks like, whether a particular attestation format is present. The same format turns up well beyond the browser: IoT and constrained-device protocols lean on CBOR because its small size suits devices with kilobytes of RAM, and it appears in some messaging, sensor and blockchain systems for the same reason. Learn to read it once and it keeps paying off.

Decode a CBOR message privately

CBOR is self-describing, so you don’t need a schema to read it — just the bytes. The CBOR Decoder takes hex or base64, decodes every major type (including tags, indefinite-length items and half/single/double floats, with 64-bit integers kept exact), and shows both the diagnostic notation and a typed tree — entirely in your browser, so a passkey response or signed token never leaves your device. (It decodes the structure; it doesn’t verify signatures.)

A typical workflow: copy the attestationObject (or any CBOR payload) as base64 or hex, paste it into the decoder, and read off the map keys and values. Because the tool runs client-side, you can safely inspect real registration responses, session tokens or device telemetry without shipping sensitive bytes to a third-party server — which, for anything touching authentication, is exactly the property you want.
