What's Inside a Font File? TTF and OTF Metadata Explained

A .ttf or .otf font isn’t one blob — it’s a small filesystem. Under the hood it’s an sfnt file: a directory of named tables, each holding one kind of information, from the glyph outlines to the family name to a licence flag that says whether you’re even allowed to embed it. Read the name table and you know exactly what font you have; read the OS/2 table and you know whether you’re allowed to ship it. Here’s what the key tables store, and how to read them with the Font Metadata Inspector.

The sfnt container: a directory of tables

Every TrueType and OpenType font starts with an offset table (also called the sfnt header) that begins with a version tag and says how many tables the font contains. It’s followed by a table directory — one record per table giving its 4-character tag, a checksum, its offset from the start of the file, and its length. To read any piece of a font, you look up the tag in the directory and jump to that offset. It’s the same idea as a ZIP’s central directory, just for font data.

That first version tag also tells you the outline flavour at a glance: 0x00010000 (often shown as 1.0) or the tag true signals TrueType outlines, while the ASCII tag OTTO signals PostScript/CFF outlines. A ttcf tag instead marks a TrueType Collection (.ttc) — several fonts sharing tables in one file, common for CJK families where the glyph data is large.

A typical font has on the order of 15–25 tables. A handful carry the metadata people actually ask about:

Table	Tag	What it holds
Naming	name	Family, style, full name, version, designer, copyright, licence
Header	head	Units-per-em, creation/modification dates, bounding box
Maximum profile	maxp	Number of glyphs
OS/2 & Windows metrics	OS/2	Weight class, width class, fsType embedding permission
Glyph outlines	glyf / CFF	The actual letter shapes (TrueType vs PostScript)

The name table: who the font says it is

The name table is a list of strings, each tagged with a name ID that says what the string means. The standard IDs you’ll run into most often:

Name ID	Meaning	Example
0	Copyright notice	”© 2001 The Font Foundry”
1	Font family	”Helvetica”
2	Font subfamily (style)	“Bold”
3	Unique identifier	internal build string
4	Full font name	”Helvetica Bold”
5	Version string	”Version 2.10”
6	PostScript name	”Helvetica-Bold”
9	Designer	”Max Miedinger”
13	Licence description	usage terms in plain text
14	Licence info URL	link to the full licence
16 / 17	Typographic family / subfamily	grouping for large families

IDs 1 and 2 are the four-style family and style that older software understands (Regular, Bold, Italic, Bold Italic); IDs 16 and 17 exist so a big family with weights like Light, Semibold and Black can group correctly in modern menus. The same string can also appear multiple times for different platforms (Windows vs Macintosh) and languages, which is why a good reader prefers the Windows/English record and de-duplicates. This table is the definitive answer to “what font is this file?” — far more reliable than the filename, which anyone can rename.

Worked example: you’re handed a file called helv-b.ttf. The filename suggests Helvetica Bold, but the name table might read family “Nimbus Sans”, subfamily “Bold”, version “Version 1.05”, copyright “URW”. Now you know it’s actually a Nimbus Sans clone, not the file you were promised — a distinction that matters for licensing.

head, maxp and OS/2: the technical facts

• head stores units-per-em (the coordinate grid — usually 2048 for TrueType, 1000 for OpenType/CFF) and the font’s creation and modification dates, counted in seconds since midnight, 1 January 1904 (the same epoch classic Mac software used). It also holds the global bounding box that encloses every glyph.
• maxp gives the glyph count, a quick gauge of how much language and symbol coverage a font has. A basic Latin face may carry a few hundred glyphs; a font covering many scripts or a full CJK set can run into the tens of thousands.
• OS/2 holds the weight class (100–900, where 400 is Regular/Normal and 700 Bold), the width class (1–9, where 5 is Medium/Normal), the Unicode and code-page coverage bitmaps, and the fsType embedding flag.

Units-per-em is worth dwelling on because it confuses people. It is not the size the font renders at — that’s your point size. It’s the resolution of the internal grid every outline is drawn on. A glyph stem that’s 82 units wide means 82/2048 of the em at 2048 upm, or 40/1000 of the em at 1000 upm; both render identically at a given point size. TrueType tooling favours a power of two (2048) because its grid-fitting maths is cleaner there, while PostScript/CFF fonts stick with 1000 for historical reasons.

fsType: the licence flag baked into the file

fsType is easy to overlook but important. It’s a bit-field in OS/2 that encodes whether — and how — the font may be embedded in a document:

fsType meaning	What it permits
Installable (value 0)	No embedding restriction at all
Restricted (bit 1 set)	No embedding permitted
Preview & Print (bit 2)	Embed for viewing/printing only, not editing
Editable (bit 3)	Embed and allow document editing

Two further bits can accompany the above: No subsetting (only the whole font may be embedded) and Bitmap embedding only (only bitmap data, not the outlines). PDF writers and presentation apps are expected to read this field and refuse to embed a restricted font, so if you’re bundling a font into a document, app or website, it’s worth checking first. One caveat: fsType reflects only what the font declares in the file — it is not a legal contract, and it isn’t a substitute for reading the actual foundry licence, which may be more or less permissive than the flag suggests.

TTF vs OTF: it’s about the outlines

Both formats share everything above; they differ in how glyph shapes are stored. A glyf table (with its companion loca index) means TrueType outlines built from quadratic Bézier curves; a CFF table (note the trailing space in the tag) means PostScript/CFF outlines built from cubic Bézier curves, which is what people usually mean by an OpenType .otf. Because OpenType is a superset that absorbed TrueType, a .ttf is technically an OpenType font too — the extension is a convention, not a hard rule, and the outline table is the real tell.

In practice the two flavours differ in ways you may notice: TrueType hinting (in the prep, fpgm and cvt tables) gives fine control over rendering at small sizes on screen, while CFF fonts tend to be a touch smaller on disk and were long favoured for print. Variable fonts add a fvar table describing their design axes (weight, width, optical size and more) on top of either outline type. The inspector reports which outline table a font carries, so you can tell a TrueType-flavoured font from a PostScript-flavoured one at a glance.

A quick tour of the tables you’ll see

Beyond the metadata tables, most fonts carry the machinery that makes them render and lay out text. You don’t usually read these by hand, but recognising the tags helps:

Tag	Role
cmap	Maps character codes (Unicode) to glyph indices
hmtx / hhea	Horizontal metrics — advance widths and side bearings
post	PostScript glyph names and italic angle
GSUB / GPOS	OpenType layout: ligatures, kerning, alternates
kern	Legacy kerning pairs (older fonts)

Seeing GSUB/GPOS tells you a font has real OpenType features (ligatures, small caps, tabular figures); their absence suggests a simpler or older font.

Read a font’s metadata privately

Because fonts are often licensed — and unreleased fonts are confidential — you don’t want to upload one to a random server just to read its name. The Font Metadata Inspector parses the sfnt tables entirely in your browser: drop in a .ttf, .otf or .ttc and it shows the family, style, version, glyph count, units-per-em, weight and embedding permission — with the file never leaving your device. (WOFF/WOFF2 web fonts are compressed; convert them to TTF/OTF first.)
