What's Inside an MP4 File? Boxes, Atoms and the 'moov' Problem

An MP4 file looks like a single container of video, but inside it’s a neat tree of labelled blocks called boxes (or atoms). Each box has a size and a four-character name, and boxes nest inside one another to form a tree. Understanding that tree explains codecs, metadata, and — most usefully — why some MP4s refuse to play or won’t start streaming. Here’s the structure, and how to look inside any file with the MP4 Box Viewer.

MP4 is a tree of boxes

MP4 and its relatives are built on the ISO Base Media File Format (ISOBMFF), where everything is a box: a size, a four-character type, and then either data or more boxes. Read from the top, a typical MP4 looks like:

ftyp   — file type & brand
moov   — movie metadata (a container)
 ├─ mvhd  — movie header (duration, timescale)
 ├─ trak  — a track (video)
 │   └─ mdia → minf → stbl → …  (codec, timing, sample tables)
 └─ trak  — a track (audio)
mdat   — the actual media samples

Three boxes carry most of the meaning: ftyp (the brand), moov (all the metadata), and mdat (the media itself).

Anatomy of a single box

Every box begins with an 8-byte header: a 4-byte size followed by a 4-byte type. The size counts the whole box including the header, so a parser can read the size, jump that many bytes, and land exactly on the next box’s header — that’s how you walk the tree without decoding anything. Two special sizes exist: a size of 1 means “the real size is a 64-bit value that follows the type” (used for boxes larger than about 4 GB, such as a big mdat), and a size of 0 means “this box runs to the end of the file.” After the header, a container box holds more boxes, while a leaf box holds fields — and many boxes are the full box variant, which adds a 1-byte version and 3-byte flags before its data.

Here are the boxes you’ll meet most often, and what each one is for:

Box	Lives inside	Container?	What it tells you
ftyp	(top level)	leaf	Major brand + compatible brands — which spec the file follows
moov	(top level)	container	The movie: all metadata a player needs before playback
mvhd	moov	leaf	Movie header: overall duration and timescale
trak	moov	container	One track (video, audio or text)
tkhd	trak	leaf	Track header: track ID, dimensions, enabled flag
mdia	trak	container	Media information for the track
hdlr	mdia	leaf	Handler type: vide, soun, subt/text
stbl	mdia → minf	container	Sample tables — the index into mdat
mdat	(top level)	leaf	The raw compressed audio/video samples
moof	(top level)	container	A fragment header (fragmented / streaming MP4)

Reading just the first level of the tree — ftyp, then moov or mdat, and in which order — already answers most practical questions about a file. The deeper boxes matter when you want codec detail.

ftyp: what kind of MP4 is this?

The first box, ftyp, declares the file’s brand — a code like isom, mp42 or qt — plus a list of compatible brands. It tells a player which version of the spec the file follows. If you’ve ever wondered whether a .mp4 is “really” an MP4 or a QuickTime MOV wearing the wrong extension, ftyp is the answer.

moov: the box that makes or breaks playback

moov is the movie box, and it holds everything a player needs before it can show a frame: the track list, durations, codec descriptions and the tables that say where each sample lives in mdat. The media data in mdat is useless without it.

This is why moov is the source of most “won’t play” problems:

• moov at the end of the file → a player can’t start until it has downloaded the whole thing, so the video won’t stream progressively. The fix is “fast start” — moving moov to the front (ffmpeg’s -movflags +faststart).
• moov missing or truncated → usually an interrupted recording (a phone that died mid-capture). The samples may be sitting in mdat, but with no moov the file is unplayable until it’s rebuilt.

Opening the box tree tells you instantly whether moov is present and whether it comes before or after mdat.

A worked example: two files, same footage

Imagine the same 200 MB clip exported two ways. A player streaming over a slow link behaves very differently depending on box order:

• Not optimised — the top level reads ftyp, then mdat, then moov. The player downloads the 200 MB of media first just to reach the metadata at the very end, so playback can’t begin until the file is essentially complete. On a web page this looks like a video that spins forever, then suddenly plays.
• Fast start — the top level reads ftyp, then moov, then mdat. The small moov arrives in the first moments, the player learns the track layout and sample offsets immediately, and playback starts while mdat is still downloading.

Same frames, same codec, same file size — only the order of two boxes changed, and one version streams while the other doesn’t. That single reordering is exactly what ffmpeg -movflags +faststart performs; it doesn’t re-encode anything, it just rewrites the file with moov moved to the front.

mdat and the tracks

mdat is just the raw, compressed media — often the biggest box by far, and opaque without moov to index it. mdat carries no labels of its own: it’s a flat run of bytes, and only the sample tables in moov (the stbl boxes) know where each frame starts, how long it lasts, and which are keyframes. That’s why a file with a healthy mdat but a damaged moov still won’t play — the media is all there, but the map is gone.

The trak boxes under moov each describe one track. Inside a track, the hdlr box names its handler — vide for video, soun for audio, subt/text for subtitles — so you can see at a glance what streams a file contains. A typical camera clip has two trak boxes (one video, one audio); a screen recording with captions might have three. Seeing more or fewer tracks than you expect is often the first clue that an export went wrong.

Fragmented MP4: when moov isn’t the whole story

Not every MP4 keeps all its metadata in one moov. Fragmented MP4 (fMP4) — used by adaptive streaming such as MPEG-DASH and HLS — splits the file into many small pieces. A slim moov at the front declares the tracks, then the media arrives as repeated moof (movie fragment) + mdat pairs, each fragment carrying its own timing so a player can start, seek, or switch quality without a giant sample table. If you inspect a streaming segment and see moof boxes instead of one big moov, that’s expected — it’s a fragmented file, not a broken one.

One structure, many extensions

Because MP4, MOV, M4A, M4V and HEIF/HEIC all sit on ISOBMFF, they share this box layout — the same ftyp/moov/mdat grammar, just different brands and handler types. A .mov from a camera and a .mp4 from an editor can be almost identical inside; the extension is mostly a hint. A single inspector reads them all, which is handy when a file has the wrong extension, refuses to open in one app but not another, or you simply want to confirm what an unfamiliar media file actually is before trusting it.

Look inside any MP4

The box tree lives in the file’s header, so you can read it without decoding a single frame. The MP4 Box Viewer walks the tree in your browser, showing each box’s type, size and offset, decoding the brand, duration and track types, and making it obvious where moov sits — so a “why won’t this play?” file gives up its answer in seconds, with nothing uploaded.
